Modular structure, IP5x dust-free certified

SALI L series projection module features a modular design. It is made up of three parts—the light source, optical engine (light path) and the power supply. The power supply’s modular structure is conducive, aiding heat dissipation. Optical engine's modular structure turns dust-free engines into reality with a gas-tight

structure that can prolong the engine's life, reducing maintenance costs.

Built-in TRIP multilayer-PIP processor

SALI L series contains a built-in TRIP multilayer-PIP processor, allowing direct signals to be convenient and flexible. Using high performance, application-specific integrated circuits (ASIC), the system can easily perform

Picture-in-Picture without Multilayer-PIP processors that allow zooming in and out, striding, piling, custom-sized window formatting and more.

Digital uniformity adjustment

The light of a normal projector concentrates in center, obscuring the corners of the unit. Digital uniformity adjustment system let the video plot out several matrix areas and calculates all the screen brightness and sets it identically.

7 Color range alignment

Traditional projectors only get RGB color adjustment. With SALI L series projection module, more colors are available with CMYW. You can adjust the individual color without affecting the base, allowing the entire screen color to be aligned perfectly.

Dual power backup (optional)

SALI L series projection module features a modular design to support the maintenance of the power supply module is hot-swappable. The interface unit will allow backup power to be supplied with a dual power design when there is a

power failure. Designed to meet the specifications of the IEC 60950, when the unit detects the circuits are powered down to 95%, it will switch to the backup power supply immediately to keeps the screen system running 7x24 hour.

10-Layer dmd board. In order to ensure the stability of the signal quality, SALI uses a specially designed use a circuit board of 10-layers, higher than the minimum requirements and proposed numbers by TI.

180W Highlight dual lamps swapping system (optional)

Using the latest Philips 180w UHP lamp, the Brightness is 35% higher than that of 132W,Intelligent lamp replacement, color brightness adjustment system can achieve a long time without maintenance. SALI is committed to service life of each 180W UHP lamp lighting for more than 6000 hours.

Dual lamps swapping system (optional)

Dual lamps switching system: One ON! another off！Due to the outstanding automatically inspection system, once one lamp conk out, another lamp be turned on immediately, and adjusted to the proper parameter.
